Specialized in foam sheet extrusion line & products

Super Flat PS Foam Board

Super Flat PS Foam Board

(Super Flat Polystyrene Foam Board)

Super Flat Polystyrene Foam Board



Features

  • Completely flat (not effected by water/humidity)
  • Very strong like plywood sheet
  • Light weight to enable any design possible
  • Easy to cut/fabricate
  • No smell and environmental friendly



Thickness Composition

Super Flat PS Foam Board Thickness

Specifications

Units Specifications
Thickness 7mm, 10mm, 12mm, 20mm, 24mm
Width 1040mm, 1240mm
Length 2000mm, 2400mm
Foam density 30kg/m3
Melamine dipping paper Kraft paper 200gr/m3 White paper 150gr/m, 180gr/m
Self adhesive coating Heat resistant grade acrylic adhesive (one side or two sides available)



Properties
Super-Flat-PS-Foam-BoardSuper-Flat-PS-Foam-Board1

Descriptions Units Specifications
Apparent density Kg/m3 30
Thermal conductivity (20 C) Kal/mhC 0.025(Max)
Compressive strength
(at 10% deformation)
Kgf/cC 1.6 ~ 2.2
Flexural strength Kgf/cC 3.0 ~ 3.7
Burn test PASS
Moisture permeability coefficient g/m hmmHg 0.06(Max)
Water absorption g/100C 0.01(Max)
Linear expansion factor cm/cmC 7 X 10-5



Applications

  • Screen/partition of office furniture
  • Display, photo mounting for signage industry
  • Backing boards, presentation board for exhibition
  • Temporary walls
